DSC DIGITAL SECURITY CONTROLS

DSC Power Series

DSC PowerSeries keypads, one stunning new touch screen and three future-smart control panels. With more than 100 added    features, the DSC PowerSeries establishes a whole different level of value with an advanced new technology platform.
pwspic2006
The new DSC PowerSeries provides a higher level of security, with all three panels compliant with the SIA CP-01 false alarm prevention standard and EN50131-1/3. The new range supports wireless, video, IP, wireless communicators, home automation, plus provides added headroom for the future. They feature a 500-event buffer, programmable daylight savings time, night zone, automatic Contact ID and partitionable auto-arm timer.
The DSC engineering team spent several years working with key customers to develop a platform that strikes a balance between advanced technical innovation and popular, practical systems—systems that are easy to sell, easy to install, easy to program, easy to upgrade and easy to use.
New PowerSeries products will begin shipping in June with some components shipping before others.
Please check with your local distributor.

Zone Expander Module PC5349
Zone Expansion Modules The strength of the PowerSeries control panel is its modular design. In addition to the hardwire zone input included with all keypads, several modules are available for hardwire, wireless and addressable zone expansion. The ability to add different technology modules to the same control panel gives you the tools to handle even the most challenging applications
PC5349

Multiple Frequency Wireless Receiver Module

  • Can be used to connect both 433MHz and 900MHz receiver
  • PowerSeries compatible
  • compatible with
    PC5132-433 V4.24
    PC5132RS v3.00+
System Keypads PC5320 (Keypad)
System Keypads To meet the demands of any application, a variety of keypads are available for the PowerSeries panels, everything from simple LED keypads to programmable LCD keypads with integrated wireless receivers. And with standard features like 5 one-touch function keys, they are all easy to use.
PC5320

    Multiple Wireless Receiver Module

  • Can be used to connect p to 4 wireless receivers -to any PowerSeries control panel for increased coverage
  • The PC5320 module supports:
    PC5132-433
    RF5108-433
(Keypad) LCD5511(Keypad)
RF5501-433

    Fixed-Message LCD Keypad with Integrated Wireless Receiver
    Includes all features of the LCD5501Z keypad and PC5132-433 wireless receiver plus:

  • Integrated low temperature detector
  • Dedicated PGM output
  • Built-in configurable input/output terminal



    LCD5511Large ICON LCD display:

  • Auto-scroll open and alarm zones
  • 4 programmable function keys
  • Clock display
  • Large buttons
  • Easily identified fire, emergency and panic buttons
  • Integrated low temperature detector
  • Built-in configurable input/output terminal
  LCD5501Z (Keypad) LCD5500Z (Keypad)
  LCD5501Z

    Fixed-Message LCD Keypad
    Large, fixed-message LCD:

  • Auto-scroll open and alarm zones
  • 5 programmable function keys
  • Built-in configurable input/output terminal
  • Clock Display
  • Door chime: 4 options, programmable by zone
  • English, French, Spanish and ICON



lcd5500z

    -Large, backlit, two-line, 32-character display

  • Plain language display of zone status, system status, trouble conditions, event buffer, system instructions, date and time
  • Auto-scroll open and alarm zones
  • Zone input
  • 5 programmable function keys
  • English, French, Spanish
433 MHz Receivers PC5132-433/PC4164-433 (Receiver) PC5320 (Receiver)
433 MHz Receivers When it’s time to add wireless detection devices to your next installation, DSC makes it easy. Turn any PowerSeries or MAXSYS alarm panel into a hybrid wireless alarm system using our proven wireless receivers. It’s as simple as adding another keypad to the existing 4-wire KEYBUS or COMBUS. Choose either an integrated wireless keypad receiver or use the stand-alone receivers. In either case, you will benefit from the exceptional performance, reliability, flexibility, and ease of installation of DSC wireless technology.



PC5132-433/PC4164-433

    Wireless Receiver

  • Supports 32/64 wireless zones, 16 wireless keys
  • PC5132-433 is compatible with all PowerSeries control panels
  • PC4164-433 is compatible with the MAXSYS® control panel
PC5320
Multiple Wireless Receiver Module
  • Can be used to connect up to 4 wireless receivers to any PowerSeries control
    panel for increased coverage
  • The PC5320 module supports:
    PC5132-433
    RF5108-433
  RF5108WKK (Receiver) WS4969 Wireless Key

RF5108WKK1
Wireless Receiver Kit
  • Ideal for those applications where only a few wireless keys and zones are required
  • 433 MHz wireless receiver
  • Supports up to eight wireless zones and eight keys
  • Dual antenna design to maximize range
  • KEYBUS compatible with PowerSeries™ control panels
  • LED switch plate (single-gang) provided
  • WS4939 four-button wireless key included
  • UL/ULC and CE approved
DSC WS4969 4-Button Wireless Key with Built-in Flashlight
  • Built-in high-intensity LED flashlight Durable, scratch resistant buttons
  • 4 programmable function keys
  • Long-life lithium batteries included
  • Full 3-second delay on panic function to reduce false alarms
  • Reliable 433 MHz technology
  • Water resistant
Wireless Keys WS4939 (Wireless Key) WS4938 (Wireless Key)
Wireless key systems are an attractive add-on to any security package, offering end users the convenience and flexibility of portable wireless remote control. These multi-purpose wireless devices not only allow users to arm/disarm any PowerSeries security systems from a distance, they can also be programmed to trigger garage door openers, turn on lights, open powered gates, or trigger a panic alarm. The applications are virtually limitless. Beyond convenience, they help reduce potential false alarms by allowing users to disarm an alarm system before entering a home or business. WS4939
  • Wireless Key
  • 4 programmable function keys
  • Small compact design
  • Integrated LED to indicate a transmission
  • Silk-screen buttons (durable, easy to see)
  • Belt clip included
  • Includes optional generic rubber button insert
  • 433 MHz technology
  • Uses long life lithium batteries
  • Full 3 second delay on panic key to reduce false alarms
WS4938
  • Activation via one large, easy-to-use button
  • Attractive, compact design
  • Full two-second delay on panic button
  • Integrated LED to indicate signal transmission
  • Neck strap included
  • Reliable 433MHz technology
  • Multifunction clip included
  • Water resistant
  • Long-life lithium batteries included
  • UL/ULC approved
  • Supervised
WS4949 (Wireless Key) WS4959 (Wireless Key) WS4939 Designer Cases (Wireless Key)
WS4949
  • Cost effective
  • Two-button, three-channel wireless key
  • Activation via two large, scratch-resistant buttons
  • Attractive, compact design Full three-second delay on panic function
  • Integrated LED to indicate signal transmission
  • Reliable 433MHz technology
  • Long-life lithium batteries included
  • FCC/IC approved
WS4959
  • 12 programmable functions
  • Attractive, compact design
  • Integrated tri-color LED to indicate signal transmission and security modes
  • Four durable, scratch-resistant buttons and center toggle button
  • Multifunction clip included
  • Reliable 433MHz technology
  • Full three-second delay on panic function
  • Long-life lithium batteries included
  • FCC/IC approved
WS4939
  • Compact, attractive design
  • Durable, scratch-resistant buttons
  • Four programmable function keys
  • Powered by long-life lithium batteries (included)
  • Full three-second delay on panic alarm to reduce false alarms
  • Multifunction belt clip
  • Reliable 433 MHz technology
  • Optional generic rubber insert
  • Eight designer cases (optional)
  • FCC, IC, UL and ULC approved
433 MHz Detectors and Devices WLS925L-433 (Detector) WS4965 Tri-Zone Contact (Detector)
When hardwiring a detector is impossible, or if time is an issue, do not hesitate to rely on DSC wireless security. Get the same great performance you expect from DSC’s proven hardwire detection devices in our comprehensive line of wireless detectors. By applying DSC wireless technology to our products, DSC offers wireless devices for every application: door/window contacts, glass break detectors, pet-immune PIRs, smoke detectors and portable panic pendants. For exceptional wireless products, security professionals worldwide turn to DSC - setting the industry standard for dependable and cost-effective wireless detectors.
WLS925L-433
Wireless Door/Window Contact
  • Built-in reed switch
  • Normally closed external contact input
  • 1 lithium battery included
  • Normally open configuration available for special order

DSC ImageThe tri-zone wireless door/window contact (model WS4965) adds value to any installation by providing installers with three zones and reliable 433 MHz technology.
• 3 zones in 1 (each zone has an individual serial number)
• Reed/Magnet combination
• Tilt switch mode for overhead doors
• 2 normally closed external contact inputs
• Long-life lithium battery included
• 1/2” (13 mm) maximum magnet gap
• Low-battery LED indicator
• Case tamper
• Reliable 433 MHz technology
• Includes backplate
• UL/ULC and FCC/IC listed
WLS904PL-433 (Detector) WLS912L-433 (detector) EV-DW4975 / WS4975W (Detector)
WLS904PL-433

Wireless Passive Infrared Detectors

  • Based on the Bravo®3D hardwire motion detector

  • High traffic shutdown

  • Pet-immunity up to 60 lbs (27 kg)

  • 1 lithium battery included

  • WLS904L-433 available in Europe

WLS912L-433

Wireless Glass break Detector
Based on the Acuity glass break detector
Tamper activated test mode:

  • Can be tested using the AFT-100 glass break tester

  • 2 lithium batteries included

DSC Image

    VANISHING CONTACT

  • Wafer-thin profile
  • Long-life lithium battery included
  • 5/8” (16 mm) magnet gap
  • Reliable 433 MHz technology
  • Includes double-sided tape
Self-contained Wireless System

The Envoy LCD security system is DSC’s most popular self-contained wireless security system. Performance and reliability are guaranteed with advanced wireless technology. The Envoy LCD offers a large real-time clock display, easy to read fixed messages, the convenience of wireless key control and personal paging. The system can be professionally installed within minutes without the disruption associated with hardwire installations, making it an excellent choice for small homes, apartments, condominiums and small businesses. Fully supervised, the Envoy LCD control unit continuously monitors system components for tampering, radio frequency jamming, low battery power, zone faults and system communication errors.

NT9005 Control Panel NT9204 WLS925L-433 (Wireless Detector)
NT9005 Control Panel

-Large fixed-message LCD display

  • LCD-driven template programming
  • Supports 32 wireless detectors, 16 wireless keys

  • Includes 2 configurable input/output terminals:

  • Zone inputs

  • PGM outputs

  • 32 user codes

  • 5 programmable function keys

  • Battery:
    DB 3.5–6 (6 volts at 3.5 amps)

NT9204

High Current Output Module

  • Provides up to 1 Amp of additional current
  • Fully supervised for AC failure, low battery and -AUX output failure

  • Provides 4 high current (1 Amp) programmable

  • Output #1 can be used as a supervised bell output

  • This module is required to power the Skyroute™ wireless transceiver

  • For use with the EnvoyLCD


WLS925L-433

    Wireless Door/Window Contact

  • Built-in reed switch

  • Normally closed external contact input

  • 1 lithium battery included

  • Normally open configuration available for special order

Photoelectric Smoke Detectors

DSC is proud to introduce our new standard for life safety security, the WS4916 wireless smoke detector with built-in heat detector. This low-profile detector incorporates automatic drift compensation, high/low sensitivity trouble and early low battery indication. Sensitivity testing has never been quicker or easier. Just hold the FSD-100 test meter near the detector for a simple, clear readout. It’s UL and ULC Listed for commercial and residential installations and is perfect for those applications where running a wire to a smoke detector is just not possible.

WS4916

    WS4916Photoelectric Smoke Detector

  • Low profile design
  • Automatic drift compensation to maintain constant sensitivity
  • High/low sensitivity trouble
  • Built-in heat detector
  • 57°C (135°F)
  • Easy maintenance replaceable chamber
  • Local test button
  • Built-in 85 dB horn
  • Built-in low battery detection
  • Unique sensitivity reading with the FSD-100 meter
  • UL Listed 268 / ULC Listed S531 for commercial and residential applications
  • Compatible with all DSC 433 MHz wireless receivers
